CPC在太阳能系统液体冷却电源逆变器的配套应用
Liquid Cooled Power Inverter - Solar Energy
太阳能和风力发电都在测试空冷功率反演的局限性,以至于液体冷却正成为一种必要。为了消除巨大的热负荷,LQ系列技术在各种清洁能源应用的高效热管理中发挥了至关重要的作用。从标准目录产品到全面设计的解决方案,CPC使产品适合您的特定应用。联系您的RSM,标准产品不适合您的应用程序,他们可以确定CPC是否会为您创建自定义产品。Solar and wind power generation are testing the limits of air-cooled power inversion to the point that liquid cooling is becoming a necessity. In order to dissipate immense heat loads, LQ series technology has played a crucial role in efficient thermal management of various clean energy applications. From standard catalog offerings to fully engineered solutions, CPC makes products to best fit your specific application. Contact your RSM a standard product does not fit your application and they can determine if CPC would create a custom product for you.
请参阅链接以了解我们的绿色定制示例的经验证的连接!See the link for our Proven Connections for an example of our green custom!
Liquid Cooled Power Inverter - Solar Energy
太阳能液冷电源逆变器
客户需要一个清洁的排水系统,用于他们的太阳能系统的液体冷却电源逆变器。The customer desired a clean draining system for their liquid cooled power inverter used on their solar energy systems.
Application:
Standard Industrial
Classification System/NAICS:
? Nonspill
? Redundantly sealed in connected state
? Low cost one piece insert design
? Aluminum material to handle abusive environment
? Custom colored green anodize
? 3/4” Elbow Body to be compatible with current
tubing commonly used on other parts of system.
? Custom G ? thread with o-ring
Features/Benefits:
120°F Max.
-40°F Max.
30 psi Max.
2 bar Max.
Water/glycol
Media: Pressure: Temperature:
Colder Part Numbers:
Custom PN
Insert – 3658202
Body - 3674000
|
